Biaxial Fabrics (+45°/-45°)
Fiberglass Biaxial Fabric are knitted of E-glass roving which are uniformly distributed in biaxial direction ( 0°/90°) or are made into combo mat by chopped strands.
They’re widely used in Boating and Wind Power, sporting appliance, boat -building, automobile , train industry etc.
Product Description
Fiberglass Biaxial Fabric are knitted of E-glass roving which are uniformly distributed in biaxial direction ( 0°/90°) or are made into combo mat by chopped strands, the weight of 0° and 90°can be arranged randomly in proportion, attaching (50-500)g/m2 CSM or Nonwoven fabric on the bottom. The total weight is 150-1200g/m2, the width is from 5-210 inches.
They’re widely used in Boating and Wind Power, sporting appliance, boat -building, automobile , train industry etc.
Features of Biaxial Fabrics (+45°/-45°)
- Excellent compatibility with EP
- Without white yarn after consolidation
- Outstanding compatible with mould
- Excellent tensile strength
Biaxial Fabrics (+45°/-45°) Speciation
| STYLE | Total Weight (g/m2) | 0° Layer (g/m2) | 90° Layer (g/m2) | Mat (g/m2) | RESIN COMPATIBILITY |
|---|---|---|---|---|---|
| EWL350-M30 | 392 | 263 | 88 | 30 | UP or Epoxy resin |
| EWL450-M30 | 502 | 354 | 107 | 30 | UP or Epoxy resin |
| EWL525-M30 | 522 | 331 | 150 | 30 | UP or Epoxy resin |
| EWL625-M30 | 636 | 449 | 144 | 30 | UP or Epoxy resin |
| EWL750-M30 | 788 | 567 | 180 | 30 | UP or Epoxy resin |
| EWL600 | 612 | 301 | 301 | / | UP or Epoxy resin |
| EWL800 | 810 | 400 | 400 | / | UP or Epoxy resin |
| EWL600-450 | 1122 | 331 | 300 | 450 | UP or Epoxy resin |
| EWL800-450 | 1276 | 413 | 402 | 450 | UP or Epoxy resin |
| EWL1200-M300 | 1520 | 606 | 600 | 300 | UP or Epoxy resin |
